30x ოპტიკური ზუმი + 3-ღერძი სტაბილიზირებულია gimbal კამერის IP გამომავალი
This is a single EO gimbal payload integrated 30x optical zoom, 3-axis stabilized PTZ and IP output. The ground receiving end IP outputs RTSP code streams, and the ground end software supports PTZ control and zoom camera control. The PTZ adopts a high-precision encoder FOC control scheme, has the characteristics of high stability, მცირე ზომის, მსუბუქი წონა და დაბალი ენერგიის მოხმარება. The camera adopts 2 mega pixels wide dynamic COMS SENSOR; Supports 1080P local TF storage and wireless transmission.
უპირატესობა
- 30xoptical zoom
- სტანდარტული RTSP ნაკადის გამომავალი
- TF ბარათის შენახვა
- Follow /lock mode
- 170MS დაბალი ლატენტობა
- 9x ციფრული მასშტაბირება
- lmage და მონაცემები იყენებენ იგივე LP
- 3-ღერძი სტაბილიზირებულია გიმბალში,655გ
მოწყობილობის სტრუქტურა

| Ვოლტაჟი | 3S-6S (11V-24V) |
| Ძალა | დინამიური 10W |
| ტექნიკური პარამეტრები | |
| გააფართოვოს კუთხე | -85—+85° |
| მოედანზე კუთხე | -90—+90° |
| ყბის კუთხე | 360° უწყვეტი როტაცია |
| Jitter კუთხე | ± 0.02 ° |
| ჰორიზონტალური ჯიტერის კუთხე | ± 0.03 ° |
| ერთი დაწკაპუნებით აღდგენა | ერთი დაწკაპუნებით აღადგინეთ საწყის მდგომარეობაში |
| რეგულირებადი ღრძილის სიჩქარე | როდესაც PTZ ბრუნავს, it conducts speed adaptation based on the current speed mode and the multiple of visible light camera. |
| კონტროლის რეჟიმი | ქსელის IP კონტროლის და სერიული პორტის კონტროლის მხარდაჭერა (SBUS და PWM კონტროლი არჩევითია) |
| დღის სენსორის პარამეტრები | |
| CMOS ზომა | 1/2.8 გრამი 2 მეგა პიქსელები ფართო დინამიური CMOS სენსორი |
| ფოკალური მანძილი | 30x ოპტიკური მასშტაბის ობიექტივი, f=4.5± 10%-135± 10%mm |
| ციფრული მასშტაბირება | 9x ციფრული მასშტაბირება |
| საათის განმავლობაში | რეალურ დროში სწრაფი ფოკუსირება, დროის ფოკუსირება < 1ს |
| ვიდეო გამომავალი | IP ქსელის გამომავალი მხარს უჭერს 4K, 1080პ, და ადგილობრივი TF შენახვა |
| ველის კუთხე (FOV) | დ : WIDE 67.8° ±5% TELE 2.77° ±5% ჰ : WIDE 59.8° +5% TELE 2.34° ±5% ვ : WIDE 40.5° ±5% TELE 1.48° ±5% |
| IP გამომავალი რეჟიმი | 1080გვ 30fps |
| Figure digital integration (სურვილისამებრ) | |
| სამუშაო სიხშირე | 806-826MHZ |
| Wireless power and transmission distance | 25DBM 10 კმ |
| კონტროლის რეჟიმი | IP, სერიული პორტი, PC side app mouse, ძირითადი ოპერაცია |
| Gimbal ზომა | 140mm X 160mm X 143mm |
| სამუშაო მდგომარეობა | -10° C- დან +50 ° C- მდე / 20% რომ 80% RH |
| შენახვის გარემო | -20° C- დან +60 ° C- მდე / 20% რომ 95% RH |
| ძირითადი პროგრამები | საჰაერო საჰაერო ფოტოგრაფია |
| წონა | 655± 10g |
