4K 20x Zoom ottico Gimbal a 3 assi, Uscita IP/HDMI
This is a drone gimbal integrated 20x optical zoom, 9x digital zoom, 4K solution, and 3-axis stabilized PTZ. It adopts HDMI/IP dual output. The PTZ adopts high-precision encoder FOC control scheme, which has the characteristics of high stability, small volume, light weight and low power consumption. The camera adopts COMS SENSOR with 8 mega effective pixels; Supports 4K and 1080P network RTSP code stream output. Both UART and IP can control the camera and PTZ, and support local TF storage.
Caratteristica
- 20x optical and 4K resolution
- 4K 1080P resolution, TF card storage
- HDM//IP dual output
- 170ms low delay RTSP output
- TF card recording, IP reading & writing
- Multiple control modes
- Ground station display & controllare
- Light weight gimbal,378G
- 3-axis stabilizer
System structure
| Voltaggio | 3S or 6S | |||
| Alimentazione elettrica | Dynamic 10W | |||
| Gimbal Feature | ||||
| Roll Angle | -45—+45° | |||
| Pitch Angle | -45—+120° | |||
| Yaw Angle | -280° —+280° | |||
| Pitch and Roll Jitter Angle | +0.02° | |||
| Horizontal Jitter Angle | +0.03° | |||
| One-Click Restore | One-click restore to the initial position | |||
| Adjustable Gimbal Speed | Low speed at big zoom status and fast speed control at small zoom status. Adaptively speed control based on zooming of daylight sensor. |
|||
| Control Way | IP,SBUS,UART control (Optional with PWM control) | |||
| Visible light Camera Para | ||||
| CMOS Size | 1/3 pollice 8 mega effective pixels CMOS SENSOR | |||
| Optical Zoom | 20x HD optical zoom lens, f=4.9±10%-49±10%mm | |||
| AF Time | Real time fast focusing, focusing time < 1s | |||
| Video Output | RTSP stream IP network output, 4K 1080P video stream local TF card storage |
|||
| Local Record | Local TF record, H.264/H265 4K, 1080P video stream | |||
| Field Angle (FOV) | D : WIDE 72° +5% TELE 3.8° ±5% H : WIDE 55.5° +5% TELE 3.0° ±5% V : WIDE 43° +5% TELE 2.2° ±5% | |||
| Support Mode | 4K 30 fps /1080P 30fps | |||
| Device ize | 109 mm *153 mm *160mm | |||
| Work Condition | -10°C to +45°C / 20% A 80% RH | |||
| Storage Condition | -20°C to +60°C / 20% A 95% RH | |||
| Mainly usage | UAV aerial photography | |||
| Peso (Not including dampers) | 635±10g | |||
